LCD

Size

55”

Resolution

3840 x 2160 ( 16:9, 1920 x1080 x 4 ch)

Pixel Pitch

0.315 mm

Color Depth

16,7M

Viewing Angle ( Typ.)

178⁰ ( H)/ 178⁰ ( v)

Luminance Max

450 cd/m²

Input

2 x Display Port

DISLAY PORT  A/B Input

4  x BNC

SDI A/B/C/D Channel Input

4 X HDMI

HDMI A/B/C/D input

Output

4 x BNC

3G- SDI A/B/C/D Channel Output ( Active Loop Through )

Input Signal

3G- SDI

2.970 Gbps

HD-SDI

1.485 Gbps

HDMI/DP

480p/ 720p/ 1080p/ 2160p

SDI Input Signal  Formats

SMPTE – 425M- A/B

1080p( 60/59.94/50/30/29.97/25/24/23.98/30sF/29.97sF/25sF/24sF/23.98sF)

SMPTE – 274M

1080p(30/29.97/25/24/23sF/23.98/23.98sF)

SMPTE – 296M

720p (60/59.94/50)

SMPTE ST 2036 – 1:2009

3840x2160(23.98/24/25/29.97/30/50/59.94/60p)

SMPTE ST 2048 – 1:2011

2048x1080(23.98/24/25/29.97/30p/psf,47.95/48/50/59.94/60p)

Audio OUT

Analog stereo ( Phone Jack )

Power

AC 100 ÷220 V ( 50 ÷60 Hz )

Power Consumption

247w

Operating Temp

0⁰ ÷ 40⁰

Storage Temp

-20⁰ ÷ 50⁰

Accessories

AC Power Cord/ Stand
